ATTACK SHARK M71 75% TKL Wireless Mechanical Keyboard User Manual

Johdanto

The ATTACK SHARK M71 is a compact 75% TKL mechanical keyboard designed for versatility and performance. Featuring a full aluminum CNC body, tri-mode connectivity (Bluetooth 5.0/3.0, 2.4G wireless, and USB-C wired), hot-swappable pre-lubed linear switches, RGB LED lighting, and a custom gasket mount, it offers a premium typing and gaming experience. This manual provides essential information for setting up, operating, and maintaining your keyboard.

Image: The ATTACK SHARK M71 keyboard showcasinsen kompaktin rakenteen ja RGB-valaistuksen ansiosta.

Pakkauksen sisältö

Varmista, että pakkauksessa on kaikki tarvittavat osat:

• ATTAC SHARK M71 -mekaaninen näppäimistö
• USB-C-USB-A-kaapeli
• 2.4G langaton vastaanotin
• Näppäimistön vetäjä
• Extra Keycaps (61 PBT OEM keycaps with GMK characters)

Image: Contents of the ATTACK SHARK M71 keyboard package, including the keyboard, cables, and accessories.

Asennus

Yhteystilat

The M71 keyboard supports three connection modes: Bluetooth, 2.4G Wireless, and Wired USB-C. You can switch between these modes using the toggle switches located on the back of the keyboard.

• Bluetooth-tila: Connects to up to 3 devices (BT 5.0 and BT 3.0). Ideal for mobile devices and general use.
• 2.4G langaton tila: Utilizes a dedicated 2.4G receiver for quick, stable connection. Suitable for gaming with low latency.
• Langallinen USB-C-tila: Connects directly via the included USB-C cable. Provides the lowest latency and charges the keyboard.

Kuva: Takaosa view of the ATTACK SHARK M71 keyboard showing the USB-C port, mode switches, and 2.4G receiver storage.

Käyttöjärjestelmän yhteensopivuus

The keyboard is widely compatible with various operating systems, including Windows 2000/XP/Vista/7/8/10/11, Android, and iOS. It also supports Mac devices.

Käyttöohjeet

Multimedia-näppäimet

The M71 features 12 multimedia keys accessible via the Fn key for quick control:

• Adjust volume (raise/lower)
• Pause/play songs
• Access calculator, email
• Control screen brightness (Fn+1/2)

RGB -valaistuksen ohjaus

The keyboard includes RGB backlighting and a side LED light strip:

• Side LED Light Strip: Paina Fn + Ctrl (R) to switch side LED light strip modes.
• RGB-taustavalo: Customize various RGB effects through the programmable software.

Image: The ATTACK SHARK M71 keyboard displaying its vibrant RGB backlighting and side light strip.

Ohjelmoitava ohjelmisto

Download the official driver software from the ATTACK SHARK website to customize lighting effects, key assignments, and macros. This allows for personalized control over your keyboard's functionality.

Ominaisuudet yliview

Hot-Swap Linear Switches

The M71 keyboard is hot-swappable, supporting both 3-pin and 5-pin switches. This allows for easy customization of keycaps and switches from various brands. The pre-lubed linear White Jade switches offer a quick, silent, and ultra-light keystroke, ideal for gaming, typing, and content creation.

Image: Close-up of the ATTACK SHARK M71 keyboard showing the hot-swappable switches.

Gasket Mount Structure & Upgraded Chip

The custom gasket mount structure incorporates anti-static IPEX switch pads, two layers of Rogers PORON sound-absorbing cotton, and two layers of PET acoustic switch pads. This design significantly reduces spring noise and hollow sounds, providing a superior typing experience. An upgraded chip optimizes latency, achieving less than 3ms in wired mode, ensuring responsive performance for gaming.

Kuva: Räjähtänyt view illustrating the multi-layered gasket mount structure of the ATTACK SHARK M71 keyboard.

CNC Aluminum Alloy Base

The keyboard features an international standard 6063 aluminum alloy shell and base with CGS certification. Utilizing CNC technology and refined polishing, it boasts a metallic luster and durable quality. The anodic oxidation technology creates a corrosion-resistant, wear-resistant, and aesthetically pleasing oxide film, ensuring long-term use.

4600mAh Battery & Power Management

Equipped with a 4600mAh large-capacity battery, the keyboard offers extended usage. In light mode, it can last 1-2 weeks, and in no-light mode, approximately 4 weeks. Check the real-time power level by pressing Fn + ALT (R) in wireless mode.

Image: Diagram showing the battery level indicator on the ATTACK SHARK M71 keyboard.

PBT OEM Keycaps

The keyboard comes with durable PBT OEM keycaps featuring GMK characters, which are more resistant to wear and oil compared to ABS materials. An additional set of 61 PBT OEM keycaps is also provided for customization.

Image: Various PBT keycaps included with the ATTACK SHARK M71 keyboard.

Huolto

To ensure the longevity and optimal performance of your ATTACK SHARK M71 keyboard, follow these maintenance guidelines:

• Puhdistus: Regularly clean the keycaps and keyboard surface with a soft, dry cloth. For deeper cleaning, use the provided keycap puller to remove keycaps and clean underneath with compressed air or a small brush.
• Kytkimen hoito: As the switches are hot-swappable, you can remove and clean them individually if needed. Avoid excessive force when removing or inserting switches.
• Kaapelin hallinta: Keep the USB-C cable organized to prevent damage.
• Varastointi: When not in use, store the keyboard in a dry, dust-free environment. The transparent dust cover can be used for protection.

Vianetsintä

If you encounter issues with your ATTACK SHARK M71 keyboard, refer to the following common solutions:

• Näppäimistö ei vastaa: Ensure the keyboard is charged and properly connected in the selected mode (wired, 2.4G, or Bluetooth). Try restarting the keyboard or your computer.
• Yhteysongelmat: For 2.4G wireless, ensure the receiver is securely plugged into a USB port. For Bluetooth, ensure the keyboard is in pairing mode and visible to your device.
• RGB-valaistus ei toimi: Check the keyboard's settings via the programmable software. Ensure the lighting is not turned off or set to a very low brightness.
• Avaimet eivät rekisteröidy: If individual keys are not working, try removing and re-inserting the switch using the switch puller. If the issue persists, the switch may need replacement.
• Akku ei lataudu: Ensure the USB-C cable is properly connected to a power source and the keyboard. The charging indicator light should flash quickly when charging.

Tekniset tiedot

Viralliset tuotevideot

Takuu ja tuki

For warranty information and customer support, please refer to the documentation included with your product or visit the official ATTACK SHARK websivusto. Säilytä ostokuitti takuuvaatimuksia varten.
