Sony Digital8 Camcorder DCR-TRV460 Instruction Manual

Johdanto

This manual provides detailed instructions for the operation and maintenance of your Sony Digital8 Camcorder DCR-TRV460. Designed for capturing and playing back memories on Digital8 and Hi8 tapes, this camcorder offers a blend of classic video recording capabilities with modern digital transfer options. Please read this manual thoroughly before using your camcorder to ensure proper operation and to maximize its lifespan.

Asennus

Pakkauksen sisältö

Ennen kuin aloitat, varmista, että pakkauksessa on kaikki tarvittavat osat:

• Sony Digital8 Camcorder DCR-TRV460
• Akku
• USB-kaapeli
• AC-sovitin
• A/V Cable (Yellow, White, Red RCA connectors)
• Käyttöopas (tämä asiakirja)

Figure 1: Included accessories for the DCR-TRV460 camcorder.

Figure 2: USB cable for data transfer.

Akun asennus ja lataus

To install the battery, align it with the battery compartment on the rear of the camcorder and slide it in until it clicks into place. To remove, press the battery release button and slide the battery out. Connect the AC adapter to the camcorder and a power outlet to charge the battery. The charging indicator will illuminate.

Camcorder Overview

Kuva 3: Etupuoli view of the DCR-TRV460 camcorder with the LCD screen open.

Kuva 4: Etuosa view of the DCR-TRV460 camcorder.

Kuva 5: Yläosa view of the DCR-TRV460 camcorder.

Käyttöohjeet

Virta päälle/pois

• To power on the camcorder, slide the POWER switch to the 'CAMERA' or 'PLAYER' position.
• To power off, slide the POWER switch to 'OFF'.

Tape Loading and Ejection

• Ensure the camcorder is in 'PLAYER' mode.
• Press the 'EJECT' button to open the tape compartment.
• Insert a Digital8 or Hi8 tape with the window facing outwards.
• Gently close the tape compartment until it locks. The camcorder will automatically load the tape.
• To eject, press the 'EJECT' button again.

Tallennus

• Slide the POWER switch to 'CAMERA'.
• Open the LCD screen or use the viewlöytäjälle.
• Press the 'START/STOP' button (located on the rear or top) to begin recording.
• Press 'START/STOP' again to pause recording.
• Use the zoom controls (front or back) to adjust magnification.

Toisto

• Slide the POWER switch to 'PLAYER'.
• Use the playback controls (Play, Rewind, Fast Forward, Stop, Pause) located on the side panel to navigate your recordings.
• The LCD screen or viewfinder will display the video.

Lisätoiminnot

The camcorder features various controls on the side panel for advanced settings, including:

• Date/Time Set: Adjust the date and time stamp for your recordings.
• Taustavalo: Activate the backlight function for improved visibility in certain lighting conditions.
• Näyttö: Toggle on-screen display information.
• Laskurin nollaus: Reset the tape counter.
• End Search: Quickly locate the end of recorded material on the tape.

Huolto

• Puhdistus: Use a soft, dry cloth to clean the exterior of the camcorder. For the lens, use a specialized lens cleaning cloth and solution.
• Varastointi: Säilytä videokameraa viileässä, kuivassa paikassa, poissa suorasta auringonvalosta ja äärimmäisistä lämpötiloista. Poista akku, jos säilytät sitä pitkään.
• Teipin hoito: Store tapes vertically in their cases to prevent damage. Avoid exposing tapes to magnetic fields.

Vianetsintä

Tekniset tiedot

Takuu ja tuki

This Sony Digital8 Camcorder DCR-TRV460 is a renewed product. Renewed products are professionally inspected and tested to work and look like new. If not satisfied with your purchase, renewed products are eligible for replacement or refund under the Amazon Renewed Guarantee.

For further assistance, please refer to the Amazon Renewed Guarantee details or contact Amazon customer support directly.
